Trimos V4 Height Gauge

Height Gauges

Digital Manual Height Gauge

The V3 and V4 vertical measuring instruments have been developed for the most difficult workshop environments. Manufactured in Switzerland, they guarantee a robust, precise and reliable product. The RF version has a fine adjustment.

The display unit provides functions that are directly accessible and depicted with symbols that are easy to understand. This allows for easy and quick handling even by unqualified personnel. The large 2-line 'Black Mask' display offers an exceptional contrast in all lighting conditions, a unique characteristic on the market.

The V3 measuring column represents the entry level Trimos universal measuring column, benefiting from the very latest in product development. The V4 offers the same functions as the V3. In addition it is equipped with a second probe holder as well as with an aircushion for easy displacement on the measuring table. The programmable functions buttons on the handle allow quick access to the most used functions.

Product Overview

Code No. Description Range (mm) Range (Inch) Maximum Error (µm) Repeatability (µm) Resolution Note
20-V4-400 Measuring range with extension - 719mm/28" 407 16 4.5 2 (Ø: 4) 0.001mm / (0.00005inch) With Air Cushion, without Fine Adjustment
20-V4-400RF Measuring range with extension - 719mm/28" 407 16 4.5 2 (Ø: 4) 0.001mm / (0.00005inch) With Air Cushion with Fine Adjustment
20-V4-700 Measuring range with extension - 1023mm/40" 711 28 6 2 (Ø: 4) 0.001mm / (0.00005inch) With Air Cushion, without Fine Adjustment
20-V4-700RF Measuring range with extension - 1023mm/40" 711 28 6 2 (Ø: 4) 0.001mm / (0.00005inch) With Air Cushion with Fine Adjustment

Everything you need to start measuring from day one.

Find out more about the Trimos V4 Height Gauge
